Nail Making Machine Supplier Unique wire feeding and retreating combination, each nail through the wire feeding, cutting,
wire retreating, three mechanical action, the nail will be completely separated from the nail shank to ensure quality.
Features
1. The machine is automatic oiled and lubricated, only few parts need lubricate oil. So the machine is very clean when working and neat in appearance.
2. It can save 60% of worker's salary with high efficiency. The equipment adopts high precision wire feeding device
can control nails length tolerence within 0.3mm, it also can keep nails head uniformity and without bent nails.
MODEL | TF-X50 | TF-X90 | TF-D90 | TF-X130 | TF-X150 |
Nail dia. | 1.8-3.0 mm | 2.0-3.8 mm | 2.0-3.5 mm | 2.4-4.0 mm | 2.5-5.0 mm |
Nail le. | 32- 55mm | 45-90 mm | 45-90 mm | 70-130 mm | 70-150 mm |
Speed | ≤800 pcs/min | ≤760pcs/min | ≤680pcs/min | ≤680pcs/min | ≤700pcs/min |
Power | 7kw | 7kw | 7kw | 7kw | 14kw |
Dim (mm) | 1350*850*1170 1500*850*1600
| 1350*1220*1050 1500*800*1600
| 1350*1220*1050 1500*800*1600
| 1550*1220*1050 1500*800*1600
| 1650*1250*1300 1500*800*1600
|
Weight | 2200 kgs | 2800 kgs | 3000 kgs | 3500 kgs | 4500 kgs |
Our advantages
●Technical advantages: Professional R&D team
●New product development advantages: Focus on product research and
development, and constantly develop new styles, add new product functions.
●Customized advantage: Products can be customized according to customers' requirement.
●High quality and on-time shipment
●24-hour online service
●20-year production and export experience
